Gamemax | PSU | GS 750G | 750 W | SFX | Full Modular

Technical details
Producer - Gamemax
Producer product family - PSU
Producer product name - GS 750G
Type - Full Modular
Gross weight - 1.87 kg
Net weight - 1.48 kg

Power
Nominal power - 750 W

Key features
80 PLUS Gold certified (efficiency up to 92% max, typically >90%)
Compact SFX form factor (dimensions approx. 125 x 110 x 65 mm or 125 x 63.5 x 110 mm)
Fully modular design with flat cables for clean cable management
ATX 3.1 and PCIe 5.1 compliant (native 12V-2×6 connector for RTX 40/50 series GPUs)
Single +12V rail (62.5A / 750W) for stable high-power delivery
90mm (or 92mm) hydraulic bearing (HDB) ultra-silent fan with intelligent PWM control and semi-passive 0dB mode (fan stops at low load)
High-quality 105°C Japanese capacitors for long-term reliability and stability
Advanced topology: Active PFC + LLC resonant + DC-DC conversion
Comprehensive protections: OPP, OVP, UVP, OCP, SCP, OTP, SIP, NLP, OLP (and more)
Universal input: 100-240V
MTBF >100,000 hours
Low noise operation (<25dBA typical)
Ideal for small form factor (SFF / Mini-ITX) high-performance builds

Warranty - 60 month(s)
