AXAGON

AXAGON | Male | 4 pin USB Type A | Male | 9 pin D-Sub (DB-9) | Black

Product code: 457187

AXAGON | Male | 4 pin USB Type A | Male | 9 pin D-Sub (DB-9) | Black

13,72 €
13,72 €
Import duties and taxes may apply outside the EU. Mains-powered products are supplied with an EU plug. Final Shipping calculated at checkout.
Order before 15:00 (EET/EEST) Dispatch within 1–2 business days
View full details

Main specifications

Technical details
Producer - Axagon
Brand - AXAGON
Model - ADS-1PSN
EAN - 8595247907646
Product Type - External USB to Serial RS232 active converter

Performance features
Power Capacity - Bus-powered
Technology - USB 2.0
Input Voltage - 5 V
Max Output Current - Shared downstream current limit
Output Connector - 1x D-Sub 9-pin RS-232 male (Input connector: 1x USB Type-A male)
Supported features - Original Prolific PL2303GT chipset with integrated driver, adjustable rates from 75 bit/s to 1000 kbit/s, 16C950 UART standard compatible, FIFO hardware buffer (768B/256B), adjustable flow control, gold-plated contacts, double-shielded 5 mm cable, Plug & Play

Design & Compatibility
Colour - Black
Housing Material - Industrial-grade heavy duty molded plastic body
Device Dimensions - 35 x 56 x 17 mm
OS Support - Microsoft Windows 11 / 10 / 8.1 / 8 / 7 / Vista / XP, Windows Server 2022 / 2019 / 2016 / 2012 / 2008 / 2003 (32/64-bit), Apple macOS 10.4 and higher, Linux kernel 2.6.x and higher, Android, Chrome OS

Dimensions & Weight
Net weight - 0.083 kg
Gross weight - 0.112 kg

Warranty – 24 month(s)
