Bosch | Serie 4 | DBB65CC60 | Built-in Hood | 582 m³/h | 3 Speeds | LED | Matte Black

Technical details
Producer – Bosch
Product type – Built-in Hood
Product line – Bosch Serie 4
Model – DBB65CC60

Design
Colour – Matte Black
Installation type – Built-in
Installation typology – Built-in/Built-under
Front panel – Clear glass

Performance
Maximum extraction rate – 582 m³/h
Maximum recirculation rate – 521 m³/h
Number of speed settings – 3
Maximum airflow – 582 m³/h

Extraction performance
Speed 1 – 349 m³/h | 54 dB(A)
Speed 2 – 458 m³/h | 60 dB(A)
Speed 3 – 583 m³/h | 65 dB(A)

Recirculation performance
Speed 1 – 333 m³/h | 61 dB(A)
Speed 2 – 441 m³/h | 68 dB(A)
Speed 3 – 521 m³/h | 72 dB(A)

Operation
Extraction – Yes
Recirculation – Yes
Recirculation kit – Required, optional accessory

Filtration
Grease filter material – Washable stainless steel
Number of grease filters – 2
Dishwasher-safe grease filters – Yes
Long-life Clean Air odour filter – Optional

Controls
Control type – Mechanical buttons
Number of speed settings – 3
Lighting control – Buttons

Lighting
Light type – LED
Number of lights – 2
Lighting power – 2 × 1.5 W
Colour temperature – 3500 K
Illumination – 316 lux
Lighting efficiency class – A

Energy Efficiency
Energy efficiency class – B
Fluid dynamic efficiency class – B
Lighting efficiency class – A
Grease filtering efficiency class – B
Annual energy consumption – 70.5 kWh/year

Noise
Maximum noise level – 65 dB(A)
Maximum recirculation noise level – 72 dB(A)

Power
Connected load – 200 W
Voltage – 220–240 V
Frequency – 50/60 Hz
Power cord length – 1.3 m
Plug type – Schuko/Gardy grounded plug

Installation
Outlet diameter – 150 mm
Additional outlet adapter – 120 mm
Minimum distance from electric hob – 43 cm
Minimum distance from gas hob – 65 cm
Required niche width – 56 cm
Required niche depth – min. 30 cm
Required niche height – 34 cm

Additional features
T-shaped design
Storage capacity – up to 20 kg
Easy installation
Easy-to-clean surfaces
Reduced fingerprint visibility
Additional side and rear steam protection
Suitable for wall-mounted cabinets
Suitable for exhaust or recirculation operation

Dimensions & Weight
Width – 59.8 cm
Depth – 29.8 cm
Height – 34 cm
Net weight – 7.8 kg

Warranty – 24 month(s)
