Thermal Grizzly | WireView | Pro GPU 1x12VHPWR Reversed | TG-WV-P-H1R

Technical details
Producer - Thermal Grizzly
Brand - Thermal Grizzly
Product Line - WireView GPU Pro
Model - TG-WV-P-H1R
Product Type - Power meters

Performance features
Type - Advanced graphics card power monitoring adapter
Input Connector - 1x 12VHPWR (PCIe 5.0 / 12V-2x6 16-pin)
Output Connector - 1x 12VHPWR (PCIe 5.0 / 12V-2x6 16-pin)
Connector Angle - 90°
Connector Pin Orientation - Reversed ("R" variant, pins oriented toward the PCB)
Display Type - OLED screen for real-time diagnostics
Integrated Sensors - Temperature sensors (internal and external) & Connector detection
Acoustic Alarm - Yes (Built-in buzzer for temperature, current limits, or loose cable alerts)
Functions - Measures power consumption (W), records peak spikes, tracks voltage (V), current (A), and pin seating

Design
Colour - Black
Material - Anodized aluminum
Shape - 90-degree angled adapter (routes the PSU cable downward towards the case floor)

Dimensions & Weight
Width - 4.3 cm
Depth - 5.2 cm
Height - 3.3 cm
Net weight - 0.039 kg
Gross weight - 0.070 kg

Warranty - 24 month(s)
